JCB – GP3600P 3.6kW / 4.5kVA Petrol Generator
SKU: JCB-G3600P
£466.99 inc VAT/£389.16 ex VAT
The JCB-G3600P is a robust and high-performance 4.5kVA petrol generator designed to meet the demands of professional applications. Equipped with a market-leading 224cc 7.5hp JCB petrol engine with an output of 3.6kW / 4.5kVA* at peak capacity. Its sturdy construction ensures reliable power generation for building and construction sites, mobile workshops, farms, and beyond!
Any questions? Need assistance? Call our helpline on 01603 756128
Product Details
Key Features:
- Powered by a 224cc 7.5hp JCB petrol engine.
- Max output of 3.6kW / 4.5kVA*, continuous output of 3.3kW / 4kVA
- Automatic Voltage Regulator (AVR), which ensures a smooth and stable power output.
- Built-in overload protection prevents damage to the alternator during operation.
- Mounted on puncture-proof tires and encased in a robust 32mm tubular steel full frame design.
- Equipped with a 230v / 16A (Blue) socket and a 115v / 16A (Yellow) socket, as well as a 12v DC 8.3A auxiliary power outlet.
- Heavy-duty recoil pull start.
- Powered by a 4-stroke petrol engine, the generator requires no fuel-oil mixing.
- Run time of over 13 hours at 50% load with its 15-litre fuel tank.
- Net Weight 50kg.
- Backed by a comprehensive 3-year warranty (1 year Commercial)*
SPECIFICATIONS
| Model | JCB-G3600P |
|---|---|
| Start Method | Recoil |
| Maximum Output kVA | 4.5 |
| Maximum Output (kW) | 3.6 |
| Continuous Output (kW) | 3.2 |
| Run Time @ 50% load (hours) | 13 |
| Fuel Consumption @ 100% load (L/Hr) | 2 |
| Fuel Consumption @ 50% load (L/Hr) | 1.15 |
| Alternator Type | AVR |
| Phase | Single Phase |
| Voltage | 115V / 230V |
| Connection Method(s) | 230V / 16A, 115V / 16A |
| Rated Speed (RPM) | 3000 |
| Frequency (Hz) | 50 |
| Max/Continuous Current (Amps) | 15.6 / 13.9 |
| Engine Model | JCB-EG225P |
| Engine Type | Petrol single cylinder |
| Engine Size (cc) | 224 |
| Engine Power (hp) | 7.5 |
| Fuel | Petrol |
| Fuel Capacity (L) | 15 |
| Engine Oil Type | 10w-30 / SAE 15w40 |
| Engine Oil Capacity (ml) | 600 |
| Low Oil Level Shutdown | Yes |
| Features | Overload Protection |
| Casing | 32mm Thick Open Frame |
| Frame Diameter (mm) | 33 |
| Noise Level db (A) @ 7m | 70 |
| Noise Level db (A) | 97 |
| Wheel Kit? | 54 |
| Gross Weight (kg) | 51 |
| Net Weight (kg) | 50 |
| Fully Assembled Dimensions (H x W x L) (mm) | 540 x 580 x 610 |
| Package Dimensions (H x W x L) (mm) | 515 x 520 x 685 |
| Fuel/Power Source | Petrol |
| Product Type | Petrol Generator |
| Home Use Warranty (years) | 3 |
| Model EAN | 5059608313055 |
| Assembly Required? | Yes - some assembly may be required |
