Holzmann – BBS550SMART-G Petrol Head Band Saw
View LargerSKU: BBS550SMART-G
£3,668.99 inc VAT/£3,057.49 ex VAT
- This version is equipped with a powerful gasoline engine for non-electric-power operation more independence in the installation location (no connection to mains)
- The cutting length depends on the number of expanding sections
- All types of timber can be cut with the same band.
- Solid and twist free construction
- Low level of required maintenance
- Easy handling
- Massive cast iron drive wheel
- Precise guide
- Eccentric clamp system
- Manual height (thickness) adjustment
- Manual cutting feed
View product video
Any questions? Need assistance? Call our helpline on 01603 756128
Product Details
Motor data
- Motor power s1 in W: 8200
- Engine type: Loncin G390F
- Displacement in cm: 389
- Fuel type: ROZ 95 (EN228)
- Fuel capacity in l: 6,5
Measurements
- Total dimensions in mm: 4260 x 1780 x 1700
Workpiece measurements
- Min. workpiece length in mm: 1050
Band saws
- Saw band in mm: 3658 x 32 x 1,1
- Saw band speed in m/min: 1200
- Flywheel diameter in mm: Ø 475
- Max. log diameter in mm: Ø 550
- Max. opening between blade guides in mm: 530
- Track section in m: 2
- Kerf thickness in mm: 1,5 – 2,2
Volume level and vibration
- Sound power level in dB(A): 98
- Sound pressure level in dB(A): 89
