Sturmer – HBS 261-2 Bandsaw
View LargerSKU: 5902426
POA
- Ideal for ambitious modellers and do-it-yourselfers
- Flywheels made of die-cast aluminum with special coating
- Aluminium cast iron worktable swiveling up to 45°
- Equipped with precise 3-rolls saw band guide above and below the table
- Aluminum longitudinal stop with quick clamping precisely adjustable with the aid of a magnifying glass and millimeter scale (except HBS 231-1)
- Two belt speeds adjustable (except HBS 231-1)
Any questions? Need assistance? Call our helpline on 01603 756128
Product Details
- Length (product) approx. 680mm
- Width/depth (product) approx. 520mm
- Height (product) approx. 1435mm
- Net weight approx. 34kg
- Extraction port diameter 100mm
- Work table length 360mm
- Work table width 320mm
- Work table height 935mm
- Work table pivot 0 – 45°
- Supply voltage 230V
- Mains frequency 50Hz
- Input power 0.375kW
- Delivery power 0.22kW
- Max. cutting height 90° 152mm
- Max. cutting height 45° 95mm
- Max. cutting width with stop 145mm
- Max. cutting width without stop 245mm
- Saw band speed(s) 400/800m/min
- Flywheel diameter 256mm
- Saw band length 1826mm
- Saw band width 10.0mm
- Saw band width max. 12.5mm
- Saw band thickness 0.35mm
