Clipper – CS1P13 18″ Floor Saw Petrol

Product Details

• Heavy duty jig welded steel frame - Robust and reliable
• Hand wheel with endless screw depth control system - Quick, easy and accurate setting
• Blade shaft mounted on "greased-for-life" pillow block bearings - Easy maintenance
• Water flow control system on both sides of the blade - Optimised blade performance

TECHNICAL DATA

• Power source: Petrol
• Motor type: HONDA GX390 Cycl.
• Power kW (Hp): 9,6kW (13 Hp)
• Max. blade x bore Ø: 500 x 25,4mm
• Max. cutting depth: 190mm
• Water tank capacity: 70 L
• Tool speed RPM: 2600 min-1
• Starter: Recoil
• Raise and lower: Manual
• Propelling: Push
• Hand Arm Vibrations: 4,22 m/s²
• Sound power/press.level: 105dB(A)/89dB(A)
• Dimensions (LxWxH): 1088 x 580 x 925mm
• Weight: 140kg
