Product Details
Electronic ignition module:
This ensures reliable starting and trouble-free running. The ignition system is fully encapsulated and thus protected from damp and dirt.Manual fuel pump (Purger)Zoom Manual fuel pump (Purger) A small fuel pump delivers fuel to the carburettor at the touch of a button. This reduces the number of starting pulls required following extended breaks in operations.
Anti-vibration system:
Anti-vibration system Intense vibration at the handles of power tools can lead to long-term effects on blood vessels in the hands and arms. STIHL has therefore developed an effective anti-vibration system whereby the oscillations from the machine's engine are dampened which significantly reduces vibrations at the handles.Long-life air filter system
Long-life air filter system:
Ensures longer cleaning intervals and better protection of the engine.Single-sided cutting blade
Single-sided cutting blade:
The double-sided cutting blade is ground on one side. The special blade geometry ensures high cutting performance.
Weight kg 1) |
4.7 |
Displacement cm³ |
27.2 |
Power output kW/bhp |
0.75/1.0 |
Weight kg 1) |
4.7 |
Vibration level left/right m/s² 2) |
10.0/9.0 |
Sound pressure level dB(A) 3) |
98.0 |
Sound power level dB(A) 3) |
105 |
Total length cm |
95cm |
Stroke rate 1/min |
3.800 |
Blade length |
450mm/18" |
Blade length cm |
45cm |
Tooth spacing mm |
30mm |
1) Without fuel, complete
2) (K) factor according to Dir. 2006/42/EC = 2m/s²
3) Power factor according to DIR2006/42/EC=2.5(dB(A))
Weight kg (1) |
5 |
Displacement cm³ |
27.2 |
Power output kW/bhp |
0.75/1.0 |
Weight kg (1) |
5.0 |
Vibration level left/right m/s² (2) |
5.6/9.7 |
Sound pressure level dB(A) (3) |
98 |
Sound power level dB(A) (3) |
105 |
Total length cm |
110 |
Stroke rate 1/min |
3.800 |
Blade length |
600mm/24" |
Blade length cm |
60 |
Tooth spacing mm |
30 |
1) Without fuel, complete
2) (K) factor according to Dir. 2006/42/EC = 2m/s²
3) Power factor according to DIR2006/42/EC=2.5(dB(A))
The engine requires a mix of petrol and engine oil. Simply mix a Stihl 50:1 two-stroke engine oil with unleaded (95 octane) petrol. The simplest method is using a standard 5 litre fuel canister and to add 0.1 litres (100 ml) of Stihl HP 2 stroke oil, close and thoroughly shake the canister and the mix is ready to use.
For this machine we recommend either Stihl HP or Stihl HP Ultra engine oil.
