Hyundai – DHY85KSE – 68kW (Three Phase) Diesel Generator
View LargerSKU: DHY85KSE
POA
The DHY85KSE is a powerful three-phase diesel generator from Hyundai. Suitable for powering three-phase equipment in your home, business or factory, this diesel genset has a maximum output of 85KVA.
PLEASE CONTACT US FOR STOCK AVAILABILITY
Any questions? Need assistance? Call our helpline on 01603 756128
Product Details
Key Features
- Three-phase diesel generator: Produces up to 85kVA of power
- Powered by a 1500rpm engine: Extends the lifespan of the generator
- Fitted with an AVR alternator: Able to produce a clean energy output
- Silenced generator: Housed in a weather-proof canopy, producing only 72dB at 7m
- ATS compatible: Automatically transfers power to the generator in the event of a power cut
- Large fuel tank: For extended running time
- Peace of mind: 2 year Hyundai warranty
Specifications
| Model | DHY85KSE |
|---|---|
| Rated/Prime kVA* | 77.5 |
| Rated/Prime kW | 62 |
| Max/Standby kVA* | 85 |
| Max/Standby kW | 68 |
| Phase | Three |
| Voltage | 230 / 400 |
| Connection Method(s) | Busbar connection only |
| Rated Speed (RPM) | 1500 |
| Frequency (Hz) | 50 |
| Max/Continuous Current (Amps) | 123 / 111 |
| Power Factor (Cosφ) | 0.8 |
| Fuel Type | Diesel |
| Fuel Tank (Litres) | 180 |
| Runtime (Hours) @ 100% Load | 10.17 |
| Noise Level @ 1m 75% load (dB) | 75 |
| Noise Level @ 7m 75% load (dB) | 70 |
| Hyundai Diesel Engine Model | HY4A100Z D20 |
| Power Output (kw) | 70 |
| Displacement (CC) | 4840 |
| No. of Cylinders | 4 |
| Displacement (Litres) | 4.84 |
| Recommended Oil Type | SAE 15W40 |
| Oil Capacity (Litres) | 13 |
| Oil Filter Part No. | 530-1012240 |
| Aspiration | Turbocharged |
| Fuel Regulation/Governor System | Electronic |
| Fuel Consumption (100% Load) [Litres] | 17.7 |
| Fuel Filter Part No. | 6105QA-1105300A |
| Cooling | Water |
| Alternator Model | 224G |
| Breakers | CDM1L-225L-125A- 4310 |
| Alternator Type | Brushless |
| Voltage Regulation | AVR |
| Air Filter Part No. | B9600-1109101*-937 |
| Net Weight (kg) | 1550 |
| Gross Weight (kg) | 1550 |
| Dimensions L x W x H (mm) | 2500 x 950 x 1520 |
| Battery System / Starting (V - Ah) | 2 x1 2V-60Ah |
| ATS / MTS Compatible | Yes |
| Control Panel | ComAp MRS23 |
| Model EAN | 600231977364 |
| Warranty | 1 Year / 1000 Hours (can extended to 2 years, subject to standby use of 500 hours per year. Terms apply*) |
