Holzmann – FKS315-VFN3200 315mm Panel Saw 415v

SKU: FKS315VFN3200

£6,169.99 inc VAT/£5,141.66 ex VAT

  • With a large professional aluminium sliding table and extension arm, ideal for processing large workpieces and cutting large, heavy panels
  • Including scorer with its own motor
  • Central control panel on the front of the machine
  • Absolutely smooth and precise saw blade height and angle adjustment using a handwheel
  • Analog angle display for reading the saw blade inclination
  • Two cutting speeds on the main circular saw blade as standard
  • Very high quality and stable machine body
  • Table widening and extension made possible
  • Comfortable working
  • Conductive aluminum sliding table with hardened
  • Steel guide rods and double rod guide
  • High dead weight enables precise machining
  • Heavy workpieces
  • Stable parallel stop with fine adjustment
  • Extendable and robust telescopic stop on the boom with 2 tilt stops
  • Max. Cutting width at the rip fence 1150mm
  • With LINIX motors


Any questions? Need assistance? Call our helpline on 01603 756128

Product Details

Motor data
  • Motor power S1 in W: 4000
  • Motor power S6 in W: 5600
  • Tension: 400V
General dimensions
  • Format sliding table in mm: n1600×375
  • Extraction connection in mm: 100
  • Table height in mm: 840
  • Table extension in mm: 600×450
  • Table size in mm: 900×570
Cutting performance
  • Cutting width at the rip fence in mm: 1150
  • Max. Cutting height 45 ° in mm: 50
  • Max. Trimming length in mm: 1600
  • Max. Cutting height 90 ° in mm: 70
Circular saws
  • Saw blade speed in min-1: 4500/5500
  • Scoring saw blade in mm: Ø120
  • Saw blade (/ hole) in mm: 305
  • Scoring saw blade speed in min-1: 8300
  • Scoring motor power in W: 750/1050
  • Saw blade swivel range: 0 ° -45 °
